The 12V battery is located under the tool tray on the top of the tractor. The 12V battery must be charged for the Monarch Tractor to power on. Without a charge from the 12V battery the tractor can’t be used.
When the Monarch Tractor sits idle, the 12V battery can quickly lose its charge. If you know the tractor won’t be charged for a day or longer, turn off the main switch. When you return to the tractor, simply switch it back on.
The 12V battery can be jumped to start the tractor. Please keep in mind that jump-starting a 12V can negatively affect the battery’s ability to hold charge over time.
12V Battery installed under the tool tray
A. 12V battery
B. Negative (-) terminal
C. Main switch in ON position
D. Positive (+) terminal
E. Ground lug; used for negative (-) terminal
IMPORTANT: The tractor cannot start if the 12V battery has lost its charge. The Start button won’t illuminate, the dashboard or Smart Screen will not turn on, and the tractor will not provide exportable power.
Keeping the 12V Battery Charged
The 12V battery loses charge repeatedly the life of the battery is affected. Eventually, a new 12V battery will be required with repeated charging and discharging.
The following options are helpful ways to maintain the 12V charge between tractor operations:
- Battery tender. Monitors and maintains the 12V battery at its optimal charge level. Battery tenders avoid over-charging the 12V battery and can protect the life of the battery
- Trickle charger. Sends a continuous low-power charge to the 12V battery.
- Store the battery indoors. If you don’t need to operate the tractor during cold weather, remove the 12V battery and store it indoors. If the tractor must be operational, insulate the tractor by covering the hood with a heavy blanket.
Given the importance of having an operational 12V battery, always keep an extra on hand. Order replacement batteries from Monarch Tractor or your dealer.
