Many systems in the Monarch Tractor MK-V rely on hydraulic fluid. To provide enough pressure for the demands, the tractor has a settling tank that provides storage for the 12 gallons on board. Follow the interval described in Scheduled Maintenance to see how frequently you need to change the hydraulic fluid.
Drain and Replace Hydraulic Fluid
Completely draining the hydraulic fluid and removing the filter. Make sure to have a large enough container to hold the used hydraulic fluid (12-gallon capacity).
Before you begin
Here’s what you’ll need to safely complete this task:
- Protective gloves
- Safety glasses
- 24mm socket wrench
- Replacement metal crush washer
- Torque wrench
- Clean container
Changing Hydraulic Fluid
To change hydraulic fluid:
- Under the tractor, locate the hydraulic fluid reservoir cap as shown below.
- Remove the drain plug.
- Remove the crush washer.
- Slide a container under the reservoir.
- Allow the hydraulic fluid to drain completely from the hydraulic fluid reservoir.
- Install a new metal crush washer.
- Replace the hydraulic fluid reservoir cap under the tractor and torque to 27Nm.
- Unscrew the hydraulic fluid dipstick near the floor of the tractor, under the seat.
- Add hydraulic fluid to the reservoir. The maximum capacity is 12 gallons.
- Once the hydraulic fluid has been replaced, dip the dipstick and then shine a black light on the dipstick to check the level in the reservoir.
🔦 Hydraulic fluid used in the Monarch Tractor is infrared. Check the level of hydraulic fluid on the dipstick with a black light.
Important: Dispose of waste properly! Polluting drains, water courses, and/or soil is illegal. Use authorized waste disposal facilities to dispose of used oil. For more information, contact your local authorized servicing dealer or the local agency for waste recycling.
